Facundo Flanges is a world-famous manufacturer and distributor of superior quality flanges based in Kuala Lumpur, Malaysia, and committed to the production of precision-crafted titanium flat flanges. The company with its strong image for reliability and innovation supplies an extensive variety of industries including aerospace, marine, chemical, and energy industries. Facundo Flanges adheres to the use of premium-grade titanium, providing outstanding corrosion resistance, strength, and durability in all products. Their skilled engineering staff and up-to-date facilities ensure that every flange is of the highest standards of performance and customer satisfaction.
The flat flanges are usually manufactured using high-quality titanium alloys including Grade 2 or Grade 5. Which has fantastic corrosion resistance and strength the presence of up to 99% titanium in this alloy. To which aluminium and vanadium additions enhance its longevity. Mechanically, titanium flat flanges have a very high tensile strength (Grade 5 up to 950 MPa) and exceptional fatigue life. The primary strengths are light weight construction, superior corrosion resistance to chemicals in sea water and high temperature and superior endurance in aggressive environments. Such characteristics make the flat titanium flanges perfectly suited for chemical processing industries, oil and gas industries, and marine uses.
| Product Name | Titanium Flat Flanges |
|---|---|
| Size Range | 1/2″ (15 NB) to 48″ (1200NB) |
| Class / Pressure Rating | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Standards / Dimensions | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, BS, GOST, MSS SP-44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605 |
| Titanium Flat Face Flanges / Connection Type | Flat Face Flange (FF), Raised Face Flange (RF), Ring Joint Flange (RTJ), Lap Joint Flange, Male and Female Flange (M&F), Large and Small Tongue-and-Groove Flange (T&G) |
| Dimensions | ANSI B16.5, ANSI B16.47 Series A & B, ASA, API-605, MSS SP44, AWWA, Custom Drawings |
| Custom Design | As per your drawing | AS, BS, ANSI, DIN, JIS | Equal and Reducing Configurations |
| Material Test Certificates (MTC) | As per EN 10204 3.2 and EN 10204 3.1, Test Certificates certifying NACE MR0175, NACE MR0103 |
| Test Certificates | 100% Radiography Test Report, EN 10204/3.1B, Raw Materials Certificate, Third Party Inspection Report, etc |
| Tests | Hydrostatic testing machine, Direct-reading Spectrograph, UI trasonic flaw detector, X-ray detector, Magnetic particle detector |
| Equipment / Machines | Press machine, Pushing Machine, Bending machine, Sand-blasting machine, electric bevelling machine, etc. |
Facundo Flanges, a leading supplier in Kuala Lumpur, Malaysia, offers an extensive selection of Titanium Flat Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Flat titanium flanges have extensive industrial use for corrosion-resistant and secure connections where many industries call upon. It is used in the oil and gas industry for those high-pressure, hostile condition pipeline systems where reliability must be a consideration. In the chemical industry as well, these flanges make for a great, corrosion-resistant seal. Along with thin marine and offshore titanium flanges that are resistant to corrosion by seawater and offer long-term performance in aggressive environments. They are applied in the power generation and aerospace sectors.
| STANDARD | UNS | WERKSTOFF NR. |
| Titanium Gr 2 | R50400 | 3.7035 |
| Titanium Gr 5 | R56400 | 3.7165 |
| Grade | C | N | O | H | Ti | Fe |
| Titanium Grade 1 | .08 Max | .03 Max | .18 Max | .015 Max | Bal | .20 Max |
| Titanium Grade 4 | .08 Max | .05 Max | .40 Max | .015 Max | Bal | .50 Max |
| Titanium Grade 7 | .08 Max | .03 Max | .25 Max | .015 Max | Bal | .30 Max |
| Titanium Grade 9 | .08 Max | .03 Max | .15 Max | .015 Max | – | .25 Max |
| Titanium Grade 12 | .08 Max | .03 Max | .25 Max | 0.15 Max | – | .30 Max |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 4.5 G/Cm3 | 1665 °C (3030 °F) | Psi – 39900 , MPa – 275 | Psi – 49900 , MPa – 344 | 20 % |
| 4.43 G/Cm3 | 1632 °C (2970 °F) | Psi – 128000 , MPa – 880 | Psi – 138000 , MPa – 950 | 14 % |
Yes, we offer custom sizes for Titanium Flat Flanges to meet specific project needs. Our team at Facundo Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@facundoflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
